**General Information**
**Image Sensor**
1/2.7″ Progressive Scan CMOS
**Effective Pixels**
5MP + 5MP
**Maximum Resolution**
2880 × 1620
**Frame Rate**
Up to 15fps; adjusts automatically during network transmission
**Pan & Tilt Features**
Pan: 350°, Tilt: 80°
**IR Distance**
Color Night Vision
Black & White Night: 30m / 98ft
**Field of View**
Fixed Lens: diagonal viewing angle of 132°, horizontal 110°, vertical 58°; Pan & Tilt Lens: diagonal 64°, horizontal 56°, vertical 29°
**Minimum Illumination**
0.5 Lux @(F1.6, with AGC ON), 0 Lux with IR (*data sourced from EZVIZ labs)
**Video Compression**
H.265 / H.264
**Audio Input/Output**
Two-Way Audio
**DNR (Digital Noise Reduction)**
3D DNR
**WDR (Wide Dynamic Range)**
Digital WDR
**Button**
Reset Button
**Storage Type**
Compatible with microSD Cards (up to 512 GB)
Supports EZVIZ CloudPlay storage
**Certifications**
CE / UKCA / WEEE / RoHS / REACH
**Additional Features**
Lens Mount: M12
Day & Night: IR-cut filter with automatic switching
**Network & Connectivity**
Wired Network
RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
**Power Supply**
DC 12V/1.5A
**Power Consumption**
Maximum 12W
**Physical Specifications**
**Color**
White
**Dimensions**
145 × 116 × 142 mm (5.71 × 4.57 × 5.59 inches)
**Weight**
Net Weight: 668 g; Package Weight: 960 g
**Other Features**
Smart Alarm: AI-Enabled Human Shape Detection, AI-Enabled Vehicle Shape Detection, Motion Detection
Auto Tracking
Customizable Alert Zone
General Functions: Anti-Flicker, Dual-Stream, Heartbeat Monitoring, Password Protection, Watermarking
**Warranty Information**
**Warranty Duration**
1 Year
