**General Information**
**Image Sensor**
1/2.7″ Progressive Scan CMOS
**Effective Pixels**
3MP + 3MP
**Maximum Resolution**
2304 × 1296
**Frame Rate**
Up to 15fps; adapts during network transmission
**Pan & Tilt**
Pan: 350°, Tilt: 80°
**Infrared Distance**
Up to 40 meters for color night vision; black and white nighttime range: 30m / 98ft
**Field of View**
Upper Camera: 2.8mm @ F1.6, viewing angle: Diagonal 130°, Horizontal 108°, Vertical 56°
Bottom Camera: 6mm @ F1.6, viewing angle: Diagonal 62°, Horizontal 55°, Vertical 28°
**Video Compression**
H.265 / H.264
**Audio Input / Output**
Two-way audio
**DNR**
3D DNR
**WDR**
Digital WDR
**Button**
Reset button
**Storage Type**
Compatible with microSD cards (up to 512 GB)
Supports EZVIZ CloudPlay storage
**Additional Features**
Minimum illumination: 0.5 Lux @(F1.6, AGC ON); 0 Lux with IR (*data sourced from EZVIZ labs)
Lens mount: M12
Day & Night: IR-cut filter with automatic switching
**Network & Connectivity**
Wired Network:
RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
**Power**
**Power Supply**
DC 12V/1.5A
**Power Consumption**
Maximum: 12W
**Physical Specifications**
**Dimensions**
145 × 116 × 142mm (5.71 × 4.57 × 5.59 inches)
**Weight**
668 g
**Additional Features**
Smart Alarm: AI-driven human and vehicle shape detection / motion detection
Auto tracking
Customizable alert zones
General functions: Anti-flicker, Dual-stream, Heartbeat monitoring, Password protection, Watermark
**Warranty Information**
**Warranty**
1 Year
