**Audio and Video Specifications**
**IP Camera Input**
– 8 Channels
**Display Interfaces**
– 2 USB 2.0 ports
– 1 RJ45 Ethernet port
– 1 HDMI port
– 1 VGA port
– 1 Audio In
– 1 Audio Out
**Resolution**
– Supports up to 5 MP
**Decoding Capability**
– 1 channel at 5 MP, 2 channels at 2 MP, 4 channels at 720p
**Recording Compression**
– Video formats: SH.265+, H.265, H.264+, H.264
– Resolutions: 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
**Playback and Backup Options**
– Search Modes: Manual, scheduled (general; motion detection; alarm; motion detection & alarm; intelligent)
– Playback Function: Synchronous playback for 4 channels
– Backup Method: USB device
**Network Connectivity**
– Ethernet Port: 1 x RJ45 (10/100 Mbps with self-adaptive technology)
**Storage**
– Internal HDD: 1 SATA port, accommodating up to 10 TB
**Auxiliary Interfaces**
– USB: 2 x USB 2.0
**Power Details**
– Power Supply: 12V DC
– Power Consumption: 4.25W (without a hard drive), 13.10W (with a hard drive)
**Operating Environment**
– Working Temperature: -10 °C to +55 °C (14 °F to 131 °F)
**Physical Dimensions**
– Size: 246.2 x 148.2 x 42.6 mm
– Weight: 0.5785 kg
**Warranty Information**
– Manufacturer’s Warranty: 1 Year
