General Information
**Image Sensor**
1/3” Progressive Scan CMOS Starlight Sensor
**Effective Pixels**
4MP
**Max. Resolution**
2560 × 1440 px
**Frame Rate**
15/20/25/30 fps
**Lens**
4.3mm focal length with an F1.6 aperture
**Pan & Tilt**
Pan Mechanical Range: 340° (360° pan coverage)
Tilt Mechanical Range: 60° (149° tilt coverage)
**Field of View**
95° (diagonal), 8° (horizontal), 40° (vertical)
**Video Compression**
H.264
**Audio Input / Output**
Two-way audio featuring noise cancellation
**DNR**
3D DNR
**WDR**
Yes
**Smart Alarm**
– Motion Detection
– Person Detection
– Line-Crossing Detection
– Tamper Detection
– Baby Cry Detection
– Vehicle Detection
– Pet Detection
– Meow Detection
– Bark Detection
– Glass-Breaking Detection
**Buttons**
1× RESET Button
1× Privacy Button
**Storage Type**
1× MicroSD Card Slot (supports up to 512 GB)
**Network & Connectivity**
Wireless Networking
Connect via Wi-Fi
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
**Power**
Power Supply: 12V DC
**Physical Specifications**
**Dimensions**
3.15 × 3.15 × 4.41 in (80 × 80 × 112 mm)
**Operating Temperature**
0℃ to 40℃
**Warranty Information**
**Warranty**
1-Year Warranty
