**General Overview**
**Image Sensor**
F1.6@1/3″ Progressive Scan CMOS
**Effective Pixels**
3MP
**Maximum Resolution**
2K (2304 × 1296p)
**Frame Rate**
Up to 25fps; adjusts automatically during network transmission
**Lens**
4mm
**IR Range**
Up to 10 meters (32.81ft)
**Field of View**
90° (Diagonal), 80° (Horizontal), 43° (Vertical)
**Video Compression Formats**
H.264/H.265
**DNR**
3D DNR
**WDR**
Digital WDR
**Smart Alarm Features**
Motion Detection, Human Detection, Human Tracking, Noise Detection, Auto Patrol
**Reset Button**
Included
**Storage Capability**
Micro SD card slot (supports up to 512GB)
**Certifications**
CE, UL, WEEE, REACH, RoHS, UKCA
**Network and Connectivity**
**Wireless Network**
IEEE802.11b, 802.11g, 802.11n
2.4 GHz to 2.4835 GHz
Supports 20MHz channel bandwidth
**Wired Network**
1 x RJ45 (10M/100M self-adaptive Ethernet port)
**Power Specifications**
**Power Ports**
Type-C
**Power Supply**
DC 5V/1A
**Power Usage**
Maximum of 5W
**Physical Details**
**Color**
White
**Dimensions**
88mm x 88.2mm x 119mm (3.46” x 3.47” x 4.69”)
**Weight**
218g (0.48lb)
**Warranty Information**
**Warranty Period**
2 Years
